Diesel Driven Hydraulic Power Pack 129HP

T3:200deg.C Zone 2

Diesel Engine Driven-Hydraulic Power Pack designed with protection system for Zone 2 potential flammable atmosphere according to EEMUA 107. The Open loop Hydraulic Power output designed to drive the heavy duty Hydraulic Slickline winch unit for well intervention services.
Technical Specification:

  • Perkins Engine type 1006-6,6cyl,6.0 Liters
  • Power rate 139HP at 2500RPM
  • Air Intake Over Speed Shutdown Valve c/w Flame Trap inside
  • Manual shut-off Lever
  • Exhaust Gas Cooler  to reduce temp <200ºC
  • Exhaust  gas & Engine Breather Flame Trap
  • Fuel & Water Coolant Safety Shutdown Valve
  • Stainless steel Spark Arrestor
  • Engine Safety Shutdown System, designed to automatic shutdown of both air intake and fuel in event of :
      • Engine over speed
      • High coolant temp. (max 100deg.C)
      • Low Oil Pressure
      • High exhaust temp. (max 200deg.C)
  • Secure Dipstick
  • Mechanical Spring Starter
  • Basic Engine Control Panel
  • 90 Liters Diesel Tank Capacity
  • 200 Liters Hydraulic Oil Tank Capacity
  • Open loop Hydraulic System with Delivery 60GPM at 2000 RPM
  • 1inch, 1-1/4 inch, & ½ inch Quick Release Hydraulic Coupling Connection
  • Frame Dimension: L2000xW1100xH1500mm
  • Maximum Gross Weight : 2000Kg
  • Forklift pockets & four points lifting eyes
  • Protective covers and side doors
  • Standard Marine top coating

Testing and Certification:

  • Structural Manufacturing Standard according to BS EN 12079 Part 1 & 2 : 2006 and  DNV 2.7-1: 2006 for standard offshore container certified by: Bureau Veritas Indonesia

User Handbook

  • General Information
  • Safety Precautions
  • Operation Instructions
  • Preventive Maintenance
  • Parts Book
